EF054 Bend Ensign Soil Long Tail Double 100mm x 88º

Article	DN	dn	Angle	Length	Height	Width	Weight
191837	70		88	312	312	78	3.1
191838	100		88	346	346	110	4.8

All dimensions are in mm and nominal weights are in kg

Product description

The Ensign cast iron long tail double bends allow a change of direction of the transported fluid, while keeping the quality and the reliability, thanks to the epoxy internal coating.

Recommended use :

• Domestic use
• Fat Wastewater
• Hot effluents
• Hydrocarbon Wastewater
• Rainwater
• Runoff water
• Industrial Wastewater

Major benefits :

The bends are generally positioned at the base of the stack in accordance with BS EN 12056 part 2 design guidance.

Technical infos

• Hot water resistance: 24h at 95°C.
• Thermal cycle resistance: 1500 cycles between 15°C and 93°C.
• Chemical resistance for 2 ≤ pH ≤ 13, up to 80°C.
• Salt spray resistance : 1500h.

Coating description :

• External coating: Red-brown, anti-corrosive acrylic primer paint, average dry film thickness 40 μm.
• Internal coating: Two-component ochre colored epoxy coating, average dry film thickness of 130 μm.

• Material : Cast Iron
• Industry product standards : BS EN877
• Range Fire Classification : Euroclass A1
• Acoustic Performance : Cast Iron performance Best in class Lsc ≤ 10 dB(A) & LaA = 47 dB(A) according to EN 14366 with 2L/s
• Percentage of Recycled Content : 97%
• Recycling Information : Virtually 100% Recyclable
