TD561 Gully Timesaver Drain Roadway with Hinged Grate and Frame DN225
Code article : 191357
Description
Heavy roadway hinged grating and frame. Grating dished 25mm deep for channel or flat.
Product variants
| Article | DN | dn | Angle | Length | Height | Width | Weight |
|---|---|---|---|---|---|---|---|
| 191357 | 225 | - | - | - | - | - | 44 |
All dimensions are in mm and nominal weights are in kg
Technical infos & product description
Product description
Heavy roadway hinged grating and frame. Grating dished 25mm deep for channel or flat.
Recommended use :
- Domestic use
- Fat Wastewater
- Aggressive effluents
- Hot effluents
- Hydrocarbon Wastewater
- Industrial Wastewater
- Rainwater
- Runoff water
Major benefits :
For use with traps/ raising pieces. Grating maximum load 7.5 tonnes. Requires caulking into fittings.
Technical infos
- Hot water resistance: 24h at 95°C
- Thermal cycle resistance: 1500 cycles between 15°C and 93°C
Coating description
- Coating: Black Water Based Primer to an average thickness of 70microns.
- Material : Cast Iron
- Industry product standards : BS 437
- Range Fire Classification :
Euroclass A1
- Percentage of Recycled Content : 97%
- Recycling Information : Fully recyclable
