EF058 Connector Ensign Soil Movement 150mm
Code article : 156235
Description
The Ensign Soil Movement Connector enables the system to have some movement were you know a solid connection would not work.
Product variants
| Article | DN | dn | Angle | Length | Height | Width | Weight |
|---|---|---|---|---|---|---|---|
| 192304 | 100 | - | 145 | 300 | 145 | 4.3 | |
| 156235 | 150 | - | 202 | 310 | 202 | 8.2 |
All dimensions are in mm and nominal weights are in kg
Technical infos & product description
Product description
The Ensign Soil Movement Connector enables the system to have some movement were you know a solid connection would not work.
Recommended use :
- Domestic use
- Fat Wastewater
- Hot effluents
- Hydrocarbon Wastewater
- Rainwater
- Runoff water
- Industrial Wastewater
Major benefits :
The Ensign cast iron blank end fitted with two rubber plugs that allows push fit connection of small diameter waste pipework in 36/42mm OD.Technical infos
- Hot water resistance: 24h at 95°C.
- Thermal cycle resistance: 1500 cycles between 15°C and 93°C.
- Chemical resistance for 2 ≤ pH ≤ 12.
- Salt spray resistance internal coating: more than 1500 h
Coating description :
- External coating: Red powder Epoxy Resin average dry film thickness 70 microns.
- Internal coating: Red powder Epoxy Resin average dry film thickness 70 microns.
- Material : Cast Iron
- Industry product standards : BS EN877
- Range Fire Classification : Euroclass A1
- Acoustic Performance : Cast Iron performance Best in class Lsc ≤ 10 dB(A) & LaA = 47 dB(A) according to EN 14366 with 2L/s
- Percentage of Recycled Content : 97%
- Recycling Information : Virtually 100% Recyclable
